| a |
18313180 |
| c |
extension 16 mm93440000 |
| b |
extension 25 mm93435000 |
| 1 |
handle93313000 |
| 2 |
safety set93337000 |
| 3 |
safety set93338000 |
| 4 |
symbol head shower93308000 |
| 5 |
symbol PowderRain outside93312000 |
| 6 |
symbol PowderRain inside93311000 |
| 7 |
symbol Mono93310000 |
| 8 |
symbol handshower93307000 |
| 9 |
adapter for symbol93398000 |
| 10 |
shower holder, assy93114000 |
| 11 |
guide (conical)94163000 |
| 12 |
hollow set screw M4x897669000 |
| 13 |
cover93325000 |
| 14 |
mounting kit93102000 |
| 15 |
O-ring 38x2,598198000 |
| 16 |
adapter for handle93109000 |
| 17 |
adapter for handle93315000 |
| 18 |
support element93330000 |
| 19 |
support element93314000 |
| 20 |
connecting thread G½93830000 |
| 21 |
O-ring 11x298127000 |
| 22 |
escutcheon93329000 |
| 23 |
thermostat cartridge96633000 |
| 24 |
sealing set96636000 |
| 25 |
O-ring 34x298383000 |
| 26 |
O-ring 26x298147000 |
| 27 |
service unit93406000 |
| 28 |
O-ring 20x298165000 |
| 29 |
non return valve96655000 |
| 30 |
filter97367000 |
| 31 |
O-ring 20x1,598197000 |
| 32 |
shut off unit98536000 |
| 33 |
Select-adapter93103000 |
| 34 |
nut98368000 |
| 35 |
shut off unit95758000 |
| 36 |
fit-up aid93487000 |
| 37 |
fit-up aid92540000 |
| 38 |
symbol head shower Rain small93663000 |
| 39 |
symbol Flood jet93309000 |
| 40 |
symbol body shower93334000 |
| 41 |
symbol Whirl93413000 |
| 42 |
symbol tub93335000 |
