AXOR Montreux
3-hole basin mixer for concealed installation wall-mounted with spout 165 - 225 mm and cross handles
Art. no. 16532003
Remember product
Product noted
Product saved for 30 daysAdd to notepad
The product could not be saved.
Please try again.
Please try again.
Compare products
Product added
Product saved for 30 daysTo the product comparison
The product could not be saved.
Please try again.
Please try again.
Special product features
Innovative technologies
Trust in highest quality
5 years warranty
Article Details
- consists of: 3-hole basin mixer for concealed installation wall-mounted, waste set
- projection: 225 mm
- handle variant: cross handle
- spray type: normal spray
- maximum flow rate at 3 bar: 7 l/min
- ceramic valves hot/cold 90°
- suitable for continuous flow water heaters
- non-closing waste set
- connection type: basic set
- connection dimension: DN15
Certificates headline lead
Certificates headline text
Downloads
Required equipment
Scope of delivery
- spout (variable length from 165 - 225 mm)
- 3-hole basin mixer
AXOR Montreux 3-hole basin mixer for concealed installation wall-mounted with spout 165 - 225 mm and cross handles
