AXOR ShowerComposition
Thermostatic Module Trim for 4 Functions

Thermostatic Module Trim for 4 Functions
Thermostatic Module Trim for 4 Functions
Change variant
Select a Variant
Thermostatic Module Trim for 4 Functions
From  USD  4,589.00
Thermostatic Module Trim for 2 Functions
From  USD  3,381.00
Thermostatic Module Trim for 3 Functions
From  USD  3,985.00
more colours available.To the special finishes
Product FinishChrome

Model No. 12573001

Remember product Product noted Product saved for 30 daysSee Wish List The product could not be saved. Please try again.
Compare Products Product added Product saved for 30 daysTo the product comparison The product could not be saved.
Please try again.
Preview at home 360° view
Product Data Sheet (PDF)
4,589.00  USD List price (U.S. dollars) is shown for comparison only. The actual retail price may be different from the price shown.
Find a local dealer
Special product features

Innovative technologies

Always constant water temperature
Thermostat
Thermostat

Always constant water temperature

Reliable: The thermostat with integrated temperature control continuously monitors the water temperature during use. It reacts quickly to changes in pressure and keeps the temperature comfortably at a constant level. For pleasant water enjoyment at all times.

For mindful use of water
Water flow control
Water flow control

For mindful use of water

The amount of water can be precisely adjusted via a control dial on the water-saving thermostat control, enabling you to use less water every day. Ideal also for children, who usually prefer gentle flow of water anyway.

Safety lock at over 40 °C
SafetyStop
SafetyStop

Safety lock at over 40 °C

A temperature limitation that ensures safe showering pleasure at all times. The function prevents too hot water from coming out of the shower. The scald protection is a big safety plus, especially for children or people with restricted mobility.

Auszeichnungen

Design Awards

iF product design award 2023
Auszeichnungen

iF product design award 2023

Products from A to Z: Those which receive this award are among the best designed in the world. This internationally recognized seal of approval has been awarded since 1953 by the International Forum Design.

Trust in highest quality

5 years warranty

Article Details

  • Consists of: thermostat module, handshower holder
  • Multiple outlets can be run simultaneously
  • Sliding movement of handle for switching water on and off, temperature and water flow control
  • Thermostat cartridge, Start/stop valve to operate the functions
  • Maximum flow rate at 60 psi: 6.3 GPM
  • Maximum flow rate with restrictor (GPM) at 80 psi: 1.75 GPM
  • Flow without restrictor (gpm): 6.3 GPM
  • Safety stop at 100 °F
  • For handshower hoses with a cylindrical nut
Certificates headline lead

Certificates

Certificates headline lead

Minimum Advertised Price (MAP)

Minimum Advertised Price (MAP)
Minimum Advertised Price (MAP)
Certificates headline lead

cUPC® Listed

cUPC® Listed products comply with applicable sections of the Uniform Plumbing Code (UPC®), National Plumbing Code of Canada, and International Plumbing Code (IPC®), as well as applicable sections of IAPMO Z124.1.2-2005 / CSA B45.5-2002

cUPC® Listed
cUPC® Listed

Downloads

Product Data Sheet (PDF)

Required parts - Select variant

Baton Handshower, 2.5 GPM
AXOR Starck Baton Handshower, 2.5 GPM
435.00USD List price (U.S. dollars) is shown for comparison only. The actual retail price may be different from the price shown.
Baton Handshower, 1.75 GPM
AXOR Starck Baton Handshower, 1.75 GPM
435.00USD List price (U.S. dollars) is shown for comparison only. The actual retail price may be different from the price shown.

REQUIRED PARTS

Rough, Thermostatic Module Select for 4 Functions, without Service Stops
Rough, Thermostatic Module Select for 4 Functions, without Service Stops
2,358.00USD List price (U.S. dollars) is shown for comparison only. The actual retail price may be different from the price shown.

Scope of delivery

  • thermostat module
  • function block
  • mounting material
  • assembly instruction

Optionales Zubehör

Textile Hose with Cylindircal Nut, 49"
AXOR ShowerSolutions Textile Hose with Cylindircal Nut, 49"
124.00USD List price (U.S. dollars) is shown for comparison only. The actual retail price may be different from the price shown.
