AXOR ShowerSolutions Thermostatic module Select 460/90 for concealed installation for 2 functions

Illustration similar

Thermostatic module Select 460/90 for concealed installation for 2 functions, Polished Gold Optic, 18355990
Thermostatic module Select 460/90 for concealed installation for 2 functions

Variant

Thermostatic module Select 460/90 for concealed installation for 2 functions
Polished Gold Optic

Surface finish

Polished Gold Optic
Planning with iSpecify What can iSpecify do? Product data sheet (PDF) Note product

Art. no.: 18355990

Product features

consists of Thermostatic module, shower holder
Eco-Function depending on volume flow and installation situation approx. 50% flow rate reduction and integrated shut off function
amount of outlet 2 outlets
use of outlets simultaneous use of several outlets
operating outlet Select push-button on/off control for 2 outlets
maximum flow rate at 0.3 MPa 26 l/min
cartridge thermostat cartridge, Select valve
min. operating pressure 1 bar
max. operating pressure 10 bar
safety stop safety lock at 40° C
temperature limitation adjustable
hose nut for shower hoses with conical or cylindrical nut on both sides
connection type basic set
Button Thermostat is delivered with buttons Waterfall, Rain large, Mono, hand shower
Test mark

ACS 18 ACC LY 046, valide jusqu'au 24.01.2023

Watermark WMK25718 / TMV

JWWA E-565

required accessory

Basic set for thermostatic module Select for 2 functions Basic set for thermostatic module Select for 2 functions
