Avoid water damage with a pre-assembled sealing membrane. It is 100% waterproof. This prevents any shower water from getting through the wall or floor for a reliable and safe showering experience.
Easy Installation
Easy Installation
Quick and safe installation
Quick and safe installation - several features ensure easy installation. With well thought-out designs and installation aids, we make our specialist partners' working lives easier.
Trust in highest quality
5 years warranty
Article Details
suitable for all new shower, bath tub and thermostat finish sets for concealed installation (AXOR ShowerSelect ID)
in conjunction with adapter plate (# 13588000) compatible with other concealed shower, bath tub and thermostat finish sets
material: dezincification brass, EPP foam, heat and sound insulating
connection thread: Rp ½
connection dimension: DN15
rotationally-symmetric installation
sound-decoupled installation
flexible mounting ring for different mounting situations
mounting ring adjustable in 5 mm steps
mounting ring suitable for front and rear installation
no shortening necessary thanks to sliding sleeve
support aid for the spirit level
integrated spirit level for correct horizontal and vertical alignment
