3-hole basin mixer 50 with escutcheons and pop-up waste set
Art. no. 11041000
| Item no. | DescriptionArticle no. |
|---|
| a | pop up waste94139000 |
| b | fixation extension 35 mm13898000 |
| c | aerator M24x1 (3,5 l/min)92508000 |
| d | aerator M24x1 (4,5 l/min)92877000 |
| e | aerator swivelling M24x1 (5 l/min)95928000 |
| 1 | spout cpl.95303000 |
| 2 | aerator M24x1 (5 l/min)13185000 |
| 3 | flat seal98749000 |
| 4 | handle for cold water95305000 |
| 5 | handle for hot water95304000 |
| 6 | O-ring 13x298128000 |
| 7 | handle fixing set98932000 |
| 8 | escutcheon95307000 |
| 9 | fixing set (Ø 32)13961000 |
| 10 | stop valve cpl.97357000 |
| 11 | shut off unit left closing94008000 |
| 12 | shut off unit right closing94009000 |
| 13 | connection hose 450 mm94071000 |
| 14 | O-ring 8x1,7597827000 |
| 15 | squeezing connection94158000 |
| 16 | connection hose 450 mm M8x0,75 G3/897206000 |
| 17 | O-ring 7x1,598422000 |
| 18 | pull rod96657000 |
| 19 | Hose extension set for 3-Hole Basin Mixer38959000 |
